DC Meter Series

DC Process Indicators

INR

A DC Process Indicator is an industrial instrument used to display and monitor process variables such as current (4–20 mA), voltage (0–10 V), temperature, pressure, flow, or other sensor signals in real time. It converts input signals from field transmitters into readable digital values for operators.

Learn More
Buy Product
Quantity
Download PDF
×

Description

A DC Process Indicator is an electronic device used to display direct current (DC) signals or measurements in a readable format. It is commonly used in industrial automation and process control systems to monitor and display the status of various parameters, such as temperature, pressure, flow, level, or voltage in DC circuits.

Product Description

Features

specifications

Product Description

A DC Process Indicator is an industrial instrument used to display and monitor process variables such as current (4–20 mA), voltage (0–10 V), temperature, pressure, flow, or other sensor signals in real time. It converts input signals from field transmitters into readable digital values for operators.

Features
  • Display solution for 0–10V DC input signal
  • Programmable up to 9999K value
  • Password protected programming
  • Reverse scaling possible (Low to High / High to Low)
  • Auto scaling response time < 1 second
  • Front push-button programming
  • RS-485 option (on demand)
DC Process Indicators - Yokins Instruments

Available Sizes

  • 72 × 72 mm
  • 48 × 96 mm
  • 96 × 96 mm
DC Process Indicators - Yokins Instruments
Specification

ParameterSpecificationInput Signal0–10V DC (Direct)Display4 Digit Red LED, Super BrightDigit Height0.56” (14.2 mm)Maximum Display9999 CountsResolution0.001 to 1 Count (Programmable)Scaling0–9999K User ProgrammableAccuracy±1 DigitOverload Capacity1.2 Times ContinuousRefresh Rate8 msDielectric Strength2.5KV @ 50Hz (1 Minute)Impulse Withstand3.5KV (1.2/50 µs)Auxiliary Supply150–300V AC / 45–270V AC/DC / 19–60V AC/DCPower ConsumptionApprox. 1.5 VAOperating Temperature0°C to +60°C (RH <70%)Storage Temperature-10°C to +70°CCalibration Temperature27°C ±5°CMounting Sizes72×72 / 48×96 / 96×96 mmStandardIEC 62053-10

Technical Specification – 0–10V DC Model


<tableclass="spec-table">
<tr><th>Parameter</th><th>Specification</th></tr>
<tr><td>Input Signal</td><td>4–20mA DC / 0–20mA DC</td></tr>
<tr><td>Display</td><td>4 Digit Red LED, Super Bright</td></tr>
<tr><td>Digit Height</td><td>0.56” (14.2 mm)</td></tr>
<tr><td>Maximum Display</td><td>9999 Counts</td></tr>
<tr><td>Resolution</td><td>0.001 to 1 Count (Programmable)</td></tr>
<tr><td>Scaling</td><td>0–9999K User Programmable</td></tr>
<tr><td>Accuracy Class</td><td>Class 1.0</td></tr>
<tr><td>Overload Capacity</td><td>1.2 Times Continuous</td></tr>
<tr><td>Refresh Rate</td><td>8 ms</td></tr>
<tr><td>Dielectric Strength</td><td>2.5KV @ 50Hz (1 Minute)</td></tr>
<tr><td>Impulse Withstand</td><td>3.5KV (1.2/50 µs)</td></tr>
<tr><td>Auxiliary Supply</td><td>150–300V AC / 45–270V AC/DC / 19–60V AC/DC</td></tr>
<tr><td>Power Consumption</td><td>Approx. 1.5 VA</td></tr>
<tr><td>Operating Temperature</td><td>0°C to +60°C (RH &lt;70%)</td></tr>
<tr><td>Storage Temperature</td><td>-10°C to +70°C</td></tr>
<tr><td>Calibration Temperature</td><td>27°C ±5°C</td></tr>
<tr><td>Mounting Sizes</td><td>72×72 / 48×96 / 96×96 mm</td></tr>
<tr><td>Standard</td><td>IEC 62053-10</td></tr>
</table>

Technical Specification – 4–20mA / 0–20mA Model
Extra Details

FAQ

  • 1. What is a DC Process Indicator?

    A DC Process Indicator is a digital panel meter used to measure and display DC signals such as 0–10V, 4–20mA, or 0–20mA coming from sensors, transmitters, or transducers.

  • 2. What input signals are supported?

    Our DC Process Indicators support:

    • 0–10V DC
    • 4–20mA DC
    • 0–20mA DC

  • 3.What is the maximum display value?

    The display is programmable up to 9999 counts (0–9999K value).
